FedSig Corner LED Hideaway Light
FedSig Corner LED
Command intersection authority from a completely covert profile with the Federal Signal 416900 Series Corner LED. Designed as the ultimate modern hideaway light, this ultra-compact, fully sealed LED unit can be installed internally inside OEM headlamp and taillamp housings or externally surface-mounted on push bumpers and tailgates. Unlike traditional strobe hideaways, the 416900 features an integrated flasher module and utilizes Federal Signal's FSJoin technology, allowing it to seamlessly synchronize with your vehicle's entire Convergence Network warning package.
Key Features & Upfitter Specs
- Application: Functions as a high-intensity internal hideaway light or a low-profile external perimeter warning light (mounting bezels and gaskets included).
- Integration: FSJoin compatibility allows for flawless "plug-and-play" synchronization with Pathfinder sirens and other Convergence Network lights.
- Performance: Emits an intense SAE J595 Class 1 warning signal with 20 selectable flash patterns, while drawing just 0.6 Amps max at 12 Vdc.
- Durability: Completely sealed to an IP67 waterproof rating, ensuring reliable operation even when surface-mounted in high-impact areas.
- Configurations: Multi-voltage (12/24 Vdc) capable; available in intense single-color or highly versatile Tri-Color LED configurations.
Specifications
| Perimeter Light Control | Standard (5-Wire), Built-In Flasher (3-Wire) |
| Light Lens | Clear, Smoked |
| Light Color | Amber, White, Blue/Amber, Red/Amber/White, Red/White, Blue/Amber/White, Red/Blue/Amber, Green/Amber/White, Red/Blue/White, Blue, Red |
| Mounting Location | Front - In The Headlights, Rear - In The Taillights, Other |
| Manufacturer | Federal Signal |
| Perimeter Light | Hideaway |
| Tags | |
|---|---|
Tags |
|
Part Numbers & Pricing 13 part numbers
| Part Number | Manufacturer | Perimeter Light | Perimeter Light Control | Light Lens | Light Color | Price | Select |
|---|---|---|---|---|---|---|---|
416912-A
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Amber | $ 77.99 | |
416912-W
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | White | $ 77.99 | |
416910Z-W
|
Federal Signal | Hideaway | Built-In Flasher (3-Wire) | Clear | White | $ 77.99 | |
416918-RAW
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Red/Amber/White | $ 70.99 | |
416900Z-BA
|
Federal Signal | Hideaway | Built-In Flasher (3-Wire) | Clear | Blue/Amber | $ 79.99 | |
416900Z-RW
|
Federal Signal | Hideaway | Built-In Flasher (3-Wire) | Clear | Red/White | $ 79.99 | |
416918-BAW
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Blue/Amber/White | $ 70.99 | |
416918-RBA
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Red/Blue/Amber | $ 70.99 | |
416918-AGW
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Green/Amber/White | $ 70.99 | |
416918-RBW-SMK
|
Federal Signal | Hideaway | Standard (5-Wire) | Smoked | Red/Blue/White | $ 85.99 | |
416918-RBW
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Red/Blue/White | $ 70.99 | |
416912-B
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Blue | $ 77.99 | |
416912-R
|
Federal Signal | Hideaway | Standard (5-Wire) | Clear | Red | $ 77.99 |
No part numbers match your filter.
Prices are per unit on your current pricelist, excluding tax and shipping. Select a row to add that part number to your cart.
