Egis Ground Block
Eliminate the erratic electrical gremlins caused by corroded chassis grounds with the Egis Mobile Electric 12-Position Sealed Ground Block (Part #2012B). Unlike traditional, exposed busbars that quickly rust in marine or winter environments, this compact distribution block is fully sealed to an IP67 rating. Capable of handling a massive 200 Amps of total return current, it provides 12 secure, moisture-proof connection points for all your auxiliary lighting, sirens, and communication equipment.
Key Features & Upfitter Specs
- Current Capacity: Handles up to 200 Amps of total continuous return current, with each of the 12 circuits rated for up to 22 Amps.
- Environmental Protection: IP67 / IP6K9K rated design completely seals internal tin-plated copper connections against dust, water, and road salt.
- Ignition Protected: SAE J1171 compliant, meaning it is perfectly safe to install in enclosed compartments containing potential fuel vapors.
- Terminals: Features a heavy-duty M8 stainless steel main input stud and highly reliable sealed plug connections for the 12 sub-circuits.
- Mounting: Compact footprint with dual mounting orientations allows for extremely flexible installation in tight vehicle consoles.
